Digital Laser Turbidity Sensor OLTU610

Digital laser turbidity sensor OLTU610

The OLTU610 is an advanced laser Turbidity Sensor tailored for high-precision water quality monitoring. Featuring an OLED display and user-friendly button operation, it is specifically designed to meet the demands of industries requiring accurate and reliable turbidity measurements. Its flow-through design and robust build ensure long-term performance with minimal maintenance.

Specifications:

• Measurement Range: 0.001~100 NTU (Resolution: 0.001 NTU)
• Accuracy:
  • 0.001~40 NTU: ±2% of reading or ±0.015 NTU, whichever is greater
  • 40~100 NTU: ±5% of reading or ±0.1 NTU, whichever is greater
• Sample Pressure: Ensure sample pressure between 1~2 Bar at the inlet
• Recommended Sample Flow Rate: 100 to 700 mL/min; Ideal: 200 to 300 mL/min
• Response Time: Initial response time < 60 seconds
• Working Temperature: 0~50°C
• Storage Temperature: -10°C to +60°C
• Body Material: ABS + SS304
• Dimensions: 140x140x330 mm
• Power Supply: 9~18 VDC
• Communication Protocol: RS485 Modbus-RTU
• Mounting Type: Wall-mounted

Key Advantages:

The OLTU610 stands out for its precision, sensitivity, and rapid response capabilities. Equipped with a 660nm laser light source, it measures turbidity by detecting microscopic particles in water with exceptional accuracy. The sensor supports automatic calibration, reducing manual intervention and enhancing reliability. Its flow-through design simplifies sample handling, making it an ideal choice for dynamic environments where ease of maintenance and operational efficiency are critical.

Additional features like its wide measuring range and low resolution (0.001 NTU) enable the detection of extremely low turbidity levels, catering to applications where water clarity is of utmost importance.

?

Applications:

• Drinking Water Quality Monitoring: Ensures compliance with water safety standards by detecting minute changes in turbidity, which could indicate contamination or filtration inefficiencies. The OLTU610 is ideal for municipal water treatment plants and portable water monitoring systems.
• Pharmaceutical Industry: Critical for maintaining water purity in pharmaceutical manufacturing processes, where even trace particles can compromise product quality. The sensor guarantees precise monitoring of purified water and process water systems.
• Food and Beverage Processing: Essential for ensuring the clarity and quality of products like beverages, syrups, and processed foods. The OLTU610 helps monitor process water and final product clarity, supporting compliance with industry standards.
• Environmental Water Monitoring: Suitable for river, lake, and reservoir monitoring to track turbidity levels and detect sediment buildup, algae blooms, or pollution sources, providing actionable insights for ecological preservation.
• Industrial Water Treatment: Used to monitor water clarity in cooling towers, boilers, and other industrial water systems, ensuring optimal performance and reducing scaling or fouling risks.

Why Choose the OLTU610?

The OLTU610 is specifically engineered for users who demand both precision and convenience. Its durable construction using ABS and SS304 materials ensures longevity, even in harsh conditions. The RS485 Modbus-RTU communication protocol makes it compatible with modern industrial systems, enabling seamless integration into existing infrastructures.

Whether for industrial, municipal, or environmental purposes, the OLTU610 offers a cost-effective, high-performance solution to meet diverse turbidity monitoring needs.
